X-4015 | |
Conveying speed (m/min) | 10-60m |
Highest detection accuracy Empty state | Stainless steel ball: Φ≥0.4mm; Ceramic ball: Φ≥0.6mm; Glass ball: Φ≥1.0mm; Metal wire: Φ≥0.3mm |
Transmission bandwidth | 370mm |
Conveyor belt height | 150mm |
Elimination method | Push rod or lever rejection (optional) |
X-ray Output | 210W - 350W (optional) |
X-ray voltage | 80-120 KV (optional) |
X-ray current | Adjustable |
X-ray emission | < 1μSv/h, including the inlet and outlet of the conveying device |
Human-computer interaction | 21.5-inch large touch screen |
Network connection | 4G /wifi ( support remote operation) |
Cooling method | Air conditioning cooling |
Elimination method | Alarm stop/flip/air blowing/push rod/push rod rejection (optional) |
Work Environment | Suitable temperature: 0~40℃ (no freezing, rapid temperature change); Suitable humidity: 30~85%RH (no condensation) |
Protection level | Transmission part IP65, other parts IP55 |
weight | 350kg |
Height from ground to conveyor belt | 800 ± 50mm (can be customized according to actual requirements) |
power supply
| AC220V, frequency 50/60 Hz, 1.5KW |
1. Superior Detection Through Aluminum Foil
X-ray technology penetrates aluminum foil, metallized film, and composite packaging without interference
Aluminum packaging material does not affect detection performance
2. Comprehensive Contaminant Detection
Metals: Iron, stainless steel, copper, aluminum, and all metal fragments
Non-metals: Glass, stones, ceramics, bones, hard plastics, rubber, and dense materials
3. Dual Function: Foreign Object + Seal Inspection
Simultaneously detects foreign contaminants and seal defects (jamming, poor sealing)
Ideal for drip bag coffee where seal quality affects shelf life
4. High-Speed Automatic Rejection
Equipped with automatic air blow/pusher/flap rejection system
Defective products are automatically removed without stopping production
5. User-Friendly Operation
Intuitive software with real-time imaging
Adjustable detection parameters for different product types
| Feature | Metal Detector | X-Ray Inspection System |
|---|---|---|
| Aluminum foil packaging | ❌ Cannot inspect effectively | ✅ Sees right through |
| Metal contaminants | ✅ Limited detection | ✅ Full detection |
| Glass, stone, bone | ❌ Cannot detect | ✅ Full detection |
| Dense plastics, ceramics | ❌ Cannot detect | ✅ Full detection |
| Seal/jamming inspection | ❌ Not available | ✅ Available |
| Product integrity check | ❌ Not available | ✅ Available |
